Economical Power Supply (R)evolution by Bihl+Wiedemann

Why New Power Supplies?

With our ASi-5 devices, you are perfectly equipped for digitization and the requirements of Industry 4.0 – especially thanks to high data bandwidth and shorter cycle times. To complement it, we are now offering a new generation of power supplies, which replaces the previous ASi power supplies. All of our new power supplies are 30 V and feature state-of-the-art technology. They are ideally suited for parallel ASi-5/ASi-3 communication. This marks the first time that a complete range of power supplies specially optimized for ASi-5 communication is available.

Bihl+Wiedemann offers the right combination for every application: Both power supplies and ASi-5/ASi-3 Gateways are perfectly matched to each other.


The Right Power Supply for Every Application

The new family of 30 V power supplies delivers the right size for every application with 4, 8 and 16 A. For example, an 8 A power supply can supply a complete double master gateway with 2 × 4 A decoupling and a single master gateway with 8 A decoupling. A 16 A power supply can supply a complete double master gateway with 2 × 8 A decoupling and two separate double master gateways with 2 × 4 A decoupling each.

The previous generation of ASi power supplies is still available for ASi repeaters and ASi-3 gateways without integrated data decoupling (in the technical data, the criterion “Integrated decoupling, ASi current measurement in the gateway” reads “no”)

Overview of our new products:
